Micsig DP700 Differential probe head
Model: DP700
The Micsig DP700 probe has two voltage ranges 70V (20X) / 700V (200X) & a bandwidth of 100 MHz
€249.00*
Content: 1
Volume discounts on request!
In Stock, Delivery time: 1 - 3 days
Further information
Product number: DP700
Features
- 100 MHz bandwidth
- 70V (20X) / 700V (200X)
Description
The DP700 probe has two voltage ranges of 70V（20X) and 700V（200X) and 100 MHz bandwidth.Micsig's DP series stands out with its high-precision, high-voltage differential probes that are ideal for critical measurement tasks in power electronics, motor control and high-voltage testing. With bandwidths ranging from 100 MHz to 500 MHz and the ability to measure voltages up to 7000Vpk, this series offers the performance needed for complex high frequency and high voltage applications.
What makes the DP series stand out is its advanced isolation technology. This technology provides exceptional common mode rejection ratio (CMRR) and minimises interference, enabling accurate detection of differential signals, even in environments with strong common mode voltages. However, if you are looking for high-end isolation technology combined with sampling of very fast slew rates at very high bandwidths, the SigOFIT series is the right choice.
The DP series is universally applicable and is particularly well suited for the development of switching power supplies, the testing of motor controls and applications such as induction heaters and inverters. Despite their robust performance, the probes are compact - with an overall height of just 2 cm and a sturdy metal housing that ensures high immunity to interference.
The user-friendliness of the DP series is enhanced by features such as automatic zeroing at the touch of a button and an overload warning, which appeals to both experienced and less experienced users. Thanks to the standard BNC interface, the DP series can be seamlessly integrated into existing oscilloscope systems, expanding the range of applications. With excellent amplitude-frequency characteristics and high input impedance, the DP series guarantees precise signal reproduction, especially when analysing small voltage changes in high-voltage applications.
Overall, the Micsig DP series is a powerful and versatile solution that impresses with its compact design, high precision and ease of use. It offers reliable and accurate results in demanding high-voltage and high-frequency applications, whether in research, development or industrial practice.
Features
Other functions
High accuracy, high CMRR
High input impedance and low input capacitance, minimised load effect, significantly improved accuracy of the differential signal. High common mode rejection capability, suitable for floating measurements of large common mode voltages at high frequencies.
CH1: @ 100 KHz, 207.7 V, output common mode signal amplitude 94.62 mV, CMRR > -60 dB
Low noise over the full bandwidth
To get an idea of the noise, short the input ends and connect them to channel 1. Set both attenuation ratios to 50X, the vertical scale to 250mV/div, the time base to 1ms and the input impedance to 1MΩ:
Noise: 40.62mV (RMS) at full bandwidth.
Excellent bandwidth flatness
The DP series probe has excellent bandwidth flatness and amplitude variations of less than 0.5dB within its half bandwidth range, high accuracy can be maintained even in high frequency bands.
Specifications
| Model comparison | Bandwidth | Differential voltage (DC+AC PK) Max. | CMRR | Input impedance |
|---|---|---|---|---|
 DP700 | 100 MHz | 70V（10X） 700V（100X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1500 | 100 MHz | Rev 1: 150V（50X） 1500V（500X） Rev 2: 150V（20X） 1500V（200X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3000 | 100 MHz | Rev 1: 300V（100X） 3000V（1000X） Rev 2: 300V（50X） 3000V（500X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
DP7000 | 100 MHz | 700V（100X） 7000V（1000X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 60MΩ / 0.78pF(differential) 30MΩ / 1.6pF(each input to ground) |
DP701 | 150 MHz | Rev 1: 70V（20X） 700V（200X） Rev 2: 70V（10X） 700V（100X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1501 | 150 MHz | Rev 1: 150V（50X） 1500V（500X） Rev 2: 150V（20X） 1500V（200X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3001 | 150 MHz | Rev 1: 300V（100X） 3000V（1000X) Rev 2: 300V（50X） 3000V（500X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
DP7001 | 150 MHz | 700V（100X） 7000V（1000X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 60MΩ / 0.78pF(differential) 30MΩ / 1.6pF(each input to ground) |
DP702 | 200 MHz | Rev 1: 70V（20X） 700V（200X） Rev 2: 70V（10X） 700V（100X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1502 | 200 MHz | Rev 1: 150V（50X） 1500V（500X） Rev 2: 150V（20X） 1500V（200X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3002 | 200 MHz | Rev 1: 300V（100X） 3000V（1000X） Rev 2: 300V（50X） 3000V（500X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
DP7002 | 200 MHz | 700V（100X） 7000V（1000X） | DC：>-80dB 100kHz: >-60dB 10MHz: >-30dB 100MHz: >-26dB | 60MΩ / 0.78pF(differential) 30MΩ / 1.6pF(each input to ground) |
DP703 | 300 MHz | 70V（20X） 700V（200X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1503 | 300 MHz | 150V（50X） 1500V（500X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3003 | 300 MHz | 300V（100X） 3000V（1000X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
DP704 | 400 MHz | 70V（20X） 700V（200X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1504 | 400 MHz | 150V（50X） 1500V（500X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3004 | 400 MHz | 300V（100X） 3000V（1000X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
DP705 | 500 MHz | 70V（20X） 700V（200X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP1505 | 500 MHz | 150V（50X） 1500V（500X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 16MΩ / 1.5pF(differential) 8MΩ / 3pF(each input to ground) |
DP3005 | 500 MHz | 300V（100X） 3000V（1000X） | DC：>-80dB 100kHz: >-70dB 10MHz: >-40dB 120MHz: >-26dB | 20MΩ / 0.5pF(differential) 10MΩ / 1pF(each input to ground) |
