Optically insulated glass fibre probes
Series overview
| Series |  SigOFIT series |
|---|---|
| Bandwidth | 100 MHz to 1 GHz |
| Interface: BNC | BNC |
| Voltage range | ±12.5 to ±6250V |
| Accuracy range | 1% |
| CMRR | DC: 180dB 128dB - 108dB |
| Noise | <0.45mVrms |
| CMVR | 85kVpk |
| Rise time | ≤3.5ns to ≤350ps |
| Series |  SigOFIT attenuation peaks |
|---|---|
| Bandwidth | 100 MHz to 1 GHz |
| Attenuation | 1X to 10000X |
| Voltage range | ±12.5 to ±6250V |
| Input impedance | 10 MΩ - 40.92MΩ / 1.0 pF - 3.0 pF |
MOIP1000P
SigOFIT MOIP1000P fibre optic probe The SigOFIT MOIP1000P (MOIP10P) optically isolated probe allows the measurement of fast switching voltages at 1 GHz.
€16,699.00*
MOIP100P
SigOFIT MOIP100P optical fibre probe The SigOFIT MOIP100P (MOIP01P) optically isolated probe allows the measurement of fast switching voltages at 100 MHz.
€2,559.00*
MOIP200P
SigOFIT MOIP200P Glass fibre probe The SigOFIT MOIP200P (MOIP02P) optically isolated probe allows the measurement of fast switching voltages at 200 MHz.
€2,749.00*
MOIP350P
SigOFIT MOIP350P Glass fibre probe The SigOFIT MOIP350P (MOIP03P) optically isolated probe allows the measurement of fast switching voltages at 350 MHz.
€4,899.00*
MOIP500P
SigOFIT MOIP500P Glass fibre probe The SigOFIT MOIP500P (MOIP05P) optically isolated probe allows the measurement of fast switching voltages at 500 MHz.
€8,999.00*
MOIP800P
SigOFIT MOIP800P fibre optic probe The SigOFIT MOIP800P (MOIP08P) optically isolated probe allows the measurement of fast switching voltages at 800 MHz.
€12,899.00*
OP10-2
SigOFIT OP10-2 Attenuation tip (10X | 200 MHz ) The OP10-2 is a 10X attenuation tip with 200 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP10-5
SigOFIT OP10-5 Attenuation tip (10X | 500 MHz ) The OP10-5 is a 10X attenuation tip with 500 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP100-2
SigOFIT OP100-2 Attenuation tip (100X | 200 MHz ) The OP100-2 is a 100X attenuation tip with 200 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP100-3
SigOFIT OP100-3 Attenuation tip (100X | 300 MHz ) The OP100-3 is a 100X attenuation tip with 300 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP100-5
SigOFIT OP100-5 Attenuation tip (100X | 500 MHz ) The OP100-5 is a 100X attenuation tip with 500 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
€1,280.00*
OP1000-1G
SigOFIT OP1000-1G Probe tip (1000X | 1 GHz) The OP1000-1G is a 1000X attenuation tip with 1 GHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
€899.00*
OP1000-2
SigOFIT OP1000-2 probe tip (1000X | 200 MHz) The OP1000-2 is a 1000X attenuation tip with 200 MHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
Product is discontinued
OP1000-3
SigOFIT OP1000-3 probe tip (1000X | 300 MHz) The OP1000-3 is a 1000X attenuation tip with 350 MHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
€299.00*
OP1000-5
SigOFIT OP1000-5 probe tip (1000X | 500 MHz) The OP1000-5 is a 1000X attenuation tip with 500 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP10000-1G
SigOFIT OP10000-1G Probe tip (10000X | 1 GHz) The OP10000-1G is a 10000X attenuation tip with 1 GHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
€1,499.00*
OP10000-5
SigOFIT OP10000-5 Probe tip (10000X | 500 MHz) The OP10000-5 is a 10000X attenuation tip with 500 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
€1,399.00*
OP20-1G
SigOFIT OP20-1G Probe tip (20X | 1 GHz) The OP20-1G is a 20X attenuation tip with 1 GHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
€1.00*
OP20-3
SigOFIT OP20-3 probe tip (20X | 300 MHz) The OP20-3 is a 20X attenuation tip with 350 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
€299.00*
OP20-5
SigOFIT OP20-5 probe tip (20X | 500 MHz) The OP20-5 is a 20X attenuation tip with 500 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
€1.00*
OP200-1G
SigOFIT OP200-1G Attenuation tip (200X | 1 GHz ) The OP200-1G is a 200X attenuation tip with 1 GHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
Product is discontinued
OP200-2
SigOFIT OP200-2 Attenuation tip (200X | 200 MHz ) The OP200-2 is a 200X attenuation tip with 200 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
Product is discontinued
OP200-3
SigOFIT OP200-3 Attenuation tip (200X | 300 MHz ) The OP200-3 is a 200X attenuation tip with 350 MHz bandwidth for the Micsig SIGOFIT fibre optic insulated series.
€299.00*
OP2000-1G
SigOFIT OP2000-1G Probe tip (2000X | 1 GHz) The OP2000-1G is a 2000X attenuation tip with 1 GHz bandwidth for the Micsig SIGOFIT fibre optic isolated series.
€899.00*
